氣墊式減震器性能以及安裝使用方式
產品性能介紹：
Product performance:
1、優異的防震消音效能， 減震器自然頻率3Hz~5Hz， 阻尼系數0.12~0.13; 低自然頻率值設計， 防振效果佳。
1. Excellent shockproof and muffler performance, natural frequency of shock absorber is 3Hz~5Hz, damping coefficient is 0.12~0.13;Low natural frequency design, good anti-vibration effect.
2、氣壓式防震裝置， 配合油壓阻尼筒設計， 內部設計阻尼機構可有效避免共振現象。
2. Pneumatic shock-proof device, combined with the design of oil-pressure damping cylinder, and the damping mechanism designed internally can effectively avoid resonance phenomenon.
3、更高的穩定性和安全性。 以金屬為主體的設計,排除因誤接觸造成的不良影響,保證產品使用穩定性和安全性。
3. Higher stability and security.The design with metal as the main body can eliminate the bad influence caused by wrong contact and ensure the stability and safety of the product.
4、通用性強。 較低高度的產品,不同規格的機器都可以輕松安裝。 適用于沖擊性設備震動， 很多設備都能適用。
4. Strong versatility.Lower height products, different specifications of the machine can be easily installed.Suitable for shock shock equipment, many equipment can be applied.
5、水平調整非常方便! 只需通過充氣和放氣就可以輕松的調整機器的水平， 非常簡單。
5. Horizontal adjustment is very convenient!It is easy to adjust the level of the machine simply by inflating and deflating.
6、易于安裝和維護。 主要用途： 沖床、 油壓裁斷機、 空壓機、 變壓器、 模切機、 三坐標測量儀、 精密工作臺、 激光加工設備;
6. Easy to install and maintain.Main applications: punching machine, hydraulic cutting machine, air compressor, transformer, die-cutting machine, CMM, precision worktable, laser processing equipment；
